Item

  Value

CPU

ARM Cortex M3 Core (Holtek HT32F2755)

Sensor

optical Sensor

Effective area of the Sensor

14 x 12.5(mm)

Image Size

 202 x 258 Pixels

Resolution

 450 dpi

The maximum number of fingerprints

200(C3) / 2000(C5) fingerprints

Matching Mode

 1:1, 1:N

The size of template

496 Bytes (template) + 2 Bytes (checksum)

Communication interface

 UART, default baud rate = 9600bps after power    on,USB Ver1.1, Full speed

False Acceptance Rate (FAR)

  < 0.001%

False Rejection Rate(FRR)

< 0.1%

Enrollment time

 < 3 sec (3 fingerprints)

Identification time

C3< 1.0 sec (200 fingerprints)/ C5<1.5 sec (2000 fingerprints)

Operating voltage

  DC 3.3~6V

Operating current

   < 130mA

Operating environment  Temperature

  -20℃  ~ +60℃;

Humidity

  20% ~ 80%

Storage environment Temperature

-20℃  ~ +60℃

Humidity

  10% ~ 80%
